Pneumonia (consolidation)



Pneumonia (consolidation)

Infection of the air spaces (air bronchograms) and/or interstitium of the lung.

Finding:

  • Depending upon the amount and distribution of the airspaces involved, this may present as confluent parenchymal (lobar or segmental) opacity or merely patchy opacity.
  • If the Interstitium is predominantly involved, it may appear as a reticulonodular pattern.
  • Air bronchograms would confirm an alveolar process.
  • The lung volume should not be lost (may even be increased).
  • Usually all radiographic abnormalities should disappear after 6 weeks of appropriate antibiotic therapy.  However, pneumonia may be complicated by abscess or empyema formation.

Examples of Pneumonias and how to determine location. (look for the silhouette sign…loss of usual visualized borders.)

Consolidation Pattern


Right Middle Lobe Consolidation


Right Middle Lobe Pneumonia


Right Lower Lobe Pneumonia


Right Lower Lobe Pneumonia, Anterior Segment


Right Lower Lobe Pneumonia, Superior Segment


Right Upper Lobe Pneumonia


Left Lingular Pneumonia


Left Lower Lobe Pneumonia, Anterior Segment


Left Lower Lobe Pneumonia, Posterior Segment

Round Pneumonia


Round Pneumonia

Round Pneumonias are found typically in the child. Most often the organism is pneumococcus. The pneumonia appears round because of poorly developed collateral pathways (pores of Kohn and channels of Lambert).  Over time though initially round, it develops into a more consolidative pattern.
